Model T501C-2BRKUS11

ION Z

  • Vivid Colors on 5.5” HD+ display
  • Protect your data and secure your favorite apps with Face unlock.
  • Speedy and responsive performance thanks to a MediaTek™ Helio A22 quad-core processor and 3GB of RAM.
  • All-day use is made possible with the robust 3000mAh battery.
  • Up to 32GB of internal memory, expandable up to 512GB via MicroSD™ card (sold separately)

Compact and Powerful with Vivid Color

The TCL ION Z is a compact device with striking vivid color on the 5.5” HD+ display. The MediaTek™ Helio A22 quad-core processor and 3GB of RAM, paired with a 3000mAh battery give speedy and responsive performance all day long. Data is secure with Face Unlock. Easily unlock your device with just a glance.

VIVID COLOR IN YOUR POCKET

See it all in striking detail with the 6” HD+ widescreen display and an impressive edge to edge 18:9 aspect ratio.

EXPERIENCE CRYSTAL CLEAR STREAMING

With 1440x720 resolution, see everything come to life on an edge to edge display and 18:9 aspect ratio.

SNAPSHOTS ON THE GO

With a 5M rear camera and 2M front camera, connect with others, record video and take beautiful photos.

SECURE AND ACCESSIBLE

Thanks to its slim design, TCL ION Z is simple to store in pockets and bags for easy accessibility and Face Unlock to make sure your info stays secure.

FAST AND SECURE

Use Face Unlock for fast and convenient access to your device with a simple glance, even in low light.

PERSONALIZED FOR YOU

Loaded with Android™ 12 so you can get the most from your device with suggested responses, actions and more intuitive gestures.

POWER THAT LASTS THOUGH OUT THE DAY

The 3000mAh battery will keep up with your daily demands and allow you to stream worry-free for hours on end.

BATTERY SAVINGS TO TAKE YOU FURTHER

The TCL Smart Manager and Battery Saver modes help keep tabs on your battery's health so you can talk, text, and surf for longer.

STRESS FREE CHARGING

Get a full charge in under 2.5 hours with the included 5V1A charger that makes powering up even easier.

PERFORMANCE THAT’S RELIABLE

Enjoy a smooth performance and stable connection with the MediaTek™ Helio A22 chipset and quad-core processor.

STORE MORE

Loaded with 3GB of RAM and 32GB of internal memory, expandable up to 512GB via MicroSD™ card2, make the TCL ION Z conveniently sized and loaded with punch.

POWERFUL AND SLEEK

Appreciate a smoother user experience thanks to the processor's amazingly snappy 2.0GHz quad-core processor.

DESIGN

DESIGN

Size

Size

146.2 x71.7x10.05mm

Weight

Weight

171g

Color

Color

Atlantic Blue

MEMORY

MEMORY

ROM/RAM

ROM/RAM

32GB / 3GB

SD Support

SD Support

Up to 512GB

User Available Memory

User Available Memory

32GB

FEATURES

FEATURES

Processor

Processor

MediaTek™ Helio A22 6761V

Speed & Type

Speed & Type

Quad-core 2.0GHz

Operating System and Version No.

Operating System and Version No.

Android 12

Sensors

Sensors

G-Sensor, P sensor, L sensor, Barometer

Fingerprint

Fingerprint

No

Facial Recognition

Facial Recognition

Yes

TTY/TTD Enabled

TTY/TTD Enabled

No

SAR Rating

SAR Rating

TBD

DISPLAY

DISPLAY

Size

Size

5.5”

Type

Type

HD+

Resolution

Resolution

1440x720

Aspect Ratio

Aspect Ratio

18:9

Glass Type

Glass Type

Tempered 2D

Touch Technology

Touch Technology

Capacitive

CONNECTIVITY

CONNECTIVITY

Network/3G/4G/LTE

Network/3G/4G/LTE

2G-GSM:850/900/1800/1900,3G-

WCDMA:B2/B4/B5,4G-FDD

LTE:B2/4/5/12(MFBI)/14/66MFBI/B30

VoLTE

VoLTE

Yes

Mobile Hotspot

Mobile Hotspot

Yes

VoWiFi

VoWiFi

Yes

Wi-Fi Specs

Wi-Fi Specs

802.11b;802.11g;802.11n

Bluetooth

Bluetooth

5.0

NFC

NFC

No

Radio

Radio

No

USB Type

USB Type

Micro-USB

SIM Type

SIM Type

Nano SIM 4FF

Card Slot

Card Slot

Single

BATTERY

BATTERY

Size

Size

3000mAh

Charging Technology

Charging Technology

5V1A

Standby Time

Standby Time

Up to 720 hrs.

Talk Time

Talk Time

Up to 24 hrs.

Charging Time Until Full

Charging Time Until Full

About 3.5 hrs.

Fast Charge

Fast Charge

No

REAR CAMERA

REAR CAMERA

Megapixels

Megapixels

5M

Flash Type

Flash Type

LCD

Focus

Focus

FF

EIS

EIS

No

Camera Video

Camera Video

Video Playback:1080P@30fps;

Video Capture:1080@30fps

FRONT CAMERA

FRONT CAMERA

Megapixels

Megapixels

2M

Flash

Flash

LCD

Focus

Focus

FF

Front Camera Video

Front Camera Video

Video Playback:720P@30fps;

Video Capture:720P@30fps

SOUND

SOUND

Number of Speakers

Number of Speakers

1

Audio Amplifier

Audio Amplifier

AW8737

Microphone

Microphone

2

HD Voice

HD Voice

Yes

Default Music Player

Default Music Player

Music Player

Supported Formats

Supported Formats

AAC LC, HE-AACv1(AAC+), HE-AACv2(enhanced AAC+), AAC ELD(enhanced low delay AAC), AMR-NB, AMR-WB, FLAC, MIDI, MP3, Opus, PCM/WAVE, Vorbis

Headset Jack Size

Headset Jack Size

3.5mm

IN BOX

IN BOX

Quick Reference Guide (QRG)

Quick Reference Guide (QRG)

Yes

Charger

Charger

5V1A

Data Cable

Data Cable

Micro USB Cable

Others

Others

SIM Card, SIM tool

Are you interested in becoming a BETA tester for TCL Mobile Products?  Click here to get more information and apply.

Take a quick survey, your feedback matters to us and could help us build mobile products that better fit your needs.



1 Screen-to-body ratio calculated with VA/TP method.

2 Requires MicroSD™ card sold separately.

3Battery life and charge cycles vary with use, settings, and other factors; actual results may vary.
